| Cat | Parameter | Unit | NiC2000 - 12 | NiC2000 - 24 | NiC2000 - 28 | NiC2000 - 48 |
|---|---|---|---|---|---|---|
| OUTPUT | Output Voltage (Nominal) | V | 12 | 24 | 28 | 48 |
| Output Voltage Adjust Range By Trimmer | V | 9.6 ~ 14.4 | 19.2 ~ 28.8 | 22.4 ~ 33.6 | 38.4 ~ 57.6 | |
| Max Output Current | A | 105 | 82 | 71 | 42 | |
| Max Output Power | W | 1260 | 1968 | 1988 | 2016 | |
| Temperature Coefficient | PPM/°C | 100 | ||||
1. OUTPUT RATING
Output Voltage (Nominal)12 V
Adjust Range By Trimmer9.6 ~ 14.4 V
Max Output Current105 A
Max Output Power1260 W
Temperature Coefficient100 PPM/°C
| Cat | Parameter | Unit | NiC2000 - 12 | NiC2000 - 24 | NiC2000 - 28 | NiC2000 - 48 |
|---|---|---|---|---|---|---|
| INPUT | Input Voltage/Freq. | — | 171 ~ 265VAC continuous, 47 ~ 63Hz, Single phase (nominal: 230VAC) | |||
| Input Current (at 230 VAC) | A | ≤10 | ||||
| Power Factor (Active PFC) | — | ≥ 0.99 (at 230VAC & full load) | ||||
| Efficiency (at 230VAC & Full load) | % | 88 | 90.4 | 91 | 92 | |
| Inrush Current (at 230VAC) | A | ≤ 40 | ||||
| Total Harmonic Distortion (THD) | % | < 5 (at 230VAC & Full load) | ||||
| Hold-up Time | ms | 10 (at 230 VAC & Full Load) | ||||
2. INPUT CHARACTERISTICS
Input Voltage Range171~265VAC, 47~63Hz
Input Current (at 230VAC)≤ 10 A
Power Factor≥ 0.99
Efficiency88%
Inrush Current≤ 40 A
THD< 5%
Hold-up Time10 ms
| Cat | Parameter | Unit | NiC2000 - 12 | NiC2000 - 24 | NiC2000 - 28 | NiC2000 - 48 |
|---|---|---|---|---|---|---|
| REGULATION | Line Regulation | % | 0.1% of full scale | |||
| Load Regulation (with remote sense connection) | % | 0.5% of full scale (With Remote Sense Connection) | ||||
| Ripple RMS, 5Hz ~ 1MHz | mV | 25 | 40 | 40 | 50 | |
3. REGULATION & RIPPLE
Line Regulation0.1% of full scale
Load Regulation0.5% of full scale
Ripple RMS (5Hz~1MHz)25 mV
| Over Current Protection | 105% of Max. Output Current |
| Over Voltage Protection | 120% of Adjusted Output Voltage |
| Remote Sense | Yes |
| Parallel Operation | Up to 4 Units |
| Output DC good | Yes |
| Remote Adjust | 1 ~ 6V Program Voltage Input to Adjust Output 40 ~ 120% Of Nominal |
| Operating Temperature | -35°C to +70°C (Derate linearly to 50% from +50°C to +70°C) |
| Storage Temperature | -40°C To +85°C |
| Humidity (Non Condensing) | Operating: 10 ~ 90%RH, Non Operating: 10 ~ 95%RH |
| Cooling | Internal variable speed fan |
| Weight | ≤ 2000 g |
| Size (W×H×D) | 127×41×295 mm |
